36 Chapter 2
Cable Preparation
Recommended Tools and Cables
Recommended Tools and Cables
Recommended Tools
For connectors such as the GTC-XXX-TX-GHZ-N (“GHZ”) connector, cable prep
tools similar to CableMatic Model SST-A (Ripley Company) are recommended.
Recommended Cables
The following table lists the recommended test lead cables for use in cable testing
applications.
Table 2-1 Recommended Test Lead Cables
Cable Description Part Number
75 Ohm Type-N 10 ft. (m-m) 8120-6737
75 Ohm Type-N 10 ft. (m-f) 8120-6740
75 Ohm Type-N 15 ft. (m-m) 8120-6738
75 Ohm Type-N 15 ft. (m-f) 8120-6741
75 Ohm Type-N 30 ft. (m-m) 8120-6739
75 Ohm Type-N 30 ft. (m-f) 8120-6742
