Appendix C 155
COM Object Reference
SCPI Objects
SCPI Objects
The SCPI objects are created to realize the SCPI commands of the E5061A/E5062A with
the COM interface.
The conversion rules from the SCPI commands when writing SCPI object messages are as
follows:
• SCPI. must be at the beginning. Notice that the IEEE common commands start with
SCPI.IEEE4882. and "*" is omitted.
• Replace colons (:) used as the hierarchical separator symbol with dots (.).
• The number written in the object message is specified with ( ).
• You cannot omit the command message in the syntax.
SCPI command COM object
OUTPUT 717;":SOUR1:POW -10" → SCPI.SOURce(1).POWer.LEVel.IMMediate.AMPLitude = -10
OUTPUT 717;":SENS1:CORR:COLL:METH:TYPE?"
ENTER 717;A$
→ A = SCPI.SENSe(1).CORRection.COLLect.METHod:TYPE
OUTPUT 717;"*CLS" → SCPI.IEEE4882.CLS
