Appendix C 191
COM Object Reference
SCPI.CALCulate(Ch).SRL.CONNector(Pt).LENGth
SCPI.CALCulate(Ch).SRL.CONNector(Pt).LENGth
Object type Property
Syntax SCPI.CALCulate(Ch).SRL.CONNector(Pt).LENGth = Va lu e
Val ue = SCPI.CALCulate(Ch).SRL.CONNector(Pt).LENGth
Description For the active trace of channels 1 to 4 (Ch), sets the connector length value for the
connector mismatch compensation.
Variable
For information on the variable (Ch), see Table C-2, “Variable (Ch),” on page 159.
Examples Dim Length As Double
SCPI.CALCulate(1).PARameter(1).SELect
SCPI.CALCulate(1).SRL.CONNector(1).LENGth = 0.1
Length = SCPI.CALCulate(1).SRL.CONNector.LENGth
Related objects SCPI.CALCulate(Ch).SRL.STATe on page 195
SCPI.CALCulate(Ch).SRL.CONNector(Pt).IMMediate on page 189
Equivalent key [Analysis] - SRL - Portx Connector - Length
Value
Description The connector length for compensation.
Data type Double precision floating point type (Double)
Range -0.02 to0.2
Preset value 0
Unit m (Meters)
