3-39
Replaceable Parts
Hardware and Other Instrument Parts
Disassembled Front Panel View
Item No. HP Part Number Qty Description
1 1250-1811 1 Adapter-Female SMA to Female Type-N
2 E4400-20012 1 Frame-Front
3 3050-1935 1 Washer-Flat
4 2190-0383 1 Washer-Lock
5 2950-0054 1 Nut-Hex 1/2-28
6 E4400-40001 1 Rubber Keypad
7 0515-1521 14 Screw-Machine M3x5 FL-TX
8 0515-0372 4 Screw-Machine M3x8 CW-PN-TX
9 1400-1594 2 Clamp-Flexible Cables
10 0515-0372 8 Screw-Machine M3x8 CW-PN-TX
11 1400-0054 1 Clamp-Semi-Rigid Cable (W9)
12 1400-1533 1 Clamp-Ribbon Cable (A1W1)
13 1400-0493 1 Cable Tie Wrap
14 1400-0611 1 Clamp-Ribbon Cable (W10)
15 E4400-00008 1 Front Frame RFI Shield
16 E4400-00009 1 Filter Bracket
17 4330-1711 1 Glass Filter 70% XMT
18 E4400-40008 1 Light Pipe
19 8160-0723 2 Ft Spiral Gasket-BC CY .094
20 8160-0660 4 Ft RFI Round Mesh.125
