Assembly Replacement

Assemblies That You Can Replace

This chapter provides removal and replacement procedures for the following assemblies:

• Instrument Cover

•Front Panel

• Front Panel (Option 1EM)

• Rear Panel

• Rear Panel (Option 1EM)

• A1 Front Panel Board

•A2 Display

• A2DS1 Fluorescent Lamp

• A3 Inverter

• A4 Power Supply

• A4 Power Supply (Option 1EM)

• A7 Baseband Generator Board (Option 1EH)

• A7 Baseband Generator Board (Options UN3 & UN4)

• A8 Data Generator Board (Options UN3 & UN4)

• A9, A11, and A12 Daughterboard Card Cage Boards

• A14 CPU/Motherboard

• A14BT1 Battery

• A15 Daughterboard

• A16 Line Module

• A17 Rear Panel Interface Board (Options 1EH, UN3, UN4)

• AT1 Electronic Attenuator/RPP

• B1 Small Fan Assembly

• B2 Large Fan Assembly

• W11, W12, and W14 Semi-Rigid Cables

After Replacing an Assembly

After you have replaced or repaired an assembly, certain performance tests and adjustments may have to be

performed. Chapter 5, "Post-Repair Procedures," lists the performance tests and adjustments required for

each assembly.
