2-17
Assembly-Level Troubleshooting with Block Diagrams
A14 CPU/Motherboard
A14 CPU/Motherboard
NOTE: The node voltages given in the following table are approximate values based on a sample
of signal generators. Your signal generator may not reflect these exact values. Additionally,
the resolution of these values varies from node to node. As a guideline, interpret your
measurements based on the number of decimal places shown for the expected voltage.
A14 CPU/Motherboard Abus Nodes
Test Conditions
Node Voltages (Corrected Values in Vdc)
DISP
LCD
INT_MOD
P10V_REF
M6V
M5V
P9V
ACOM
PRESET; 5.3 0.00 10 6.0 5.2 9.0 0.00
PRESET; Vary Display Brightness 1 to 50 0.4 to
1.3
