5-2
Post-Repair Procedures
Performance Tests
Performance Tests
The following matrix shows you which performance tests must be performed when a specific assembly is
repaired or replaced. Except where noted, all tests are automated using software. Refer to the “HP ESG-D
Series Signal Generators Calibration Guide” for more information on performance tests.
Performance Tests
Performance Tests
Repaired/Replaced Assembly
A1 Front Panel Bd A2 Display A2DS1 Lamp A3 Inverter A4 Power Supply A7 Baseband Gen Bd A8 Data Gen Bd A9 Output Bd A11 Reference Bd A12 Synthesizer Bd A14 Motherboard A14BT1 Battery A15 Daughterboard A16 Line Module A17 Rear Panel Bd AT1 Attenuator
AM Frequency Response ● ● ● ● ●
Burst Modulation On/Off Ratio ● ● ● ● ●
DCFM Frequency Offset ● ● ● ● ● ●
Digital Mod: Power Level Accuracy ● ● ● ●
FM Frequency Response ● ● ● ● ●
Harmonics ● ● ● ● ● ●
Internal AM Accuracy ● ● ● ● ●
Internal AM Distortion ● ● ● ● ●
Internal FM Accuracy ● ● ● ● ●
Internal FM Distortion ● ● ● ● ●
Nonharmonics ● ● ● ● ● ● ● ●
Phase Modulation Accuracy ● ● ● ● ●
Phase Modulation Distortion ● ● ● ● ●
PM Frequency Response ● ● ● ● ●
Power Level Accuracy
●
1
●
1
●
1
●
1
● ● ● ●
●
2
●
2
●
Pulse Modulation On/Off Ratio ● ● ● ●
Residual FM ● ● ● ● ●
Subharmonics ● ● ● ● ●
Timebase Aging Rate
3
● ● ● ●
