8 Contacting Hewlett-Packard

This chapter prepares you for contacting Hewlett-Packard should you have a problem with your signal

generator. This chapter is organized into the following sections:

• Before Contacting HP

• Calling HP Sales and Service Offices

• Returning Your Signal Generator for Service

• Blue Repair Tags
