4-8
Assembly Replacement
Front Panel
7. Carefully peel off the side trim (item 1) from the sides of the front panel assembly (item 2).
8. Remove the four screws (item 3) that attach the front panel assembly to the instrument chassis.
9. Pull the front panel assembly away f
rom the instrument chassis.
Replacement
1. Reverse the removal procedure and do the following:
• Refer to Chapter 3, "Replaceable Parts," to verify that the cables are reconn
ected in the correct locations.
• To reconnect W10 to its motherboard connector do the following:
a Ensure the motherboard connector is unlocked by pulling out the locking mechanism (much like pulling
o
ut a drawer).
b Insert W10 into the connector making sure the conductive con
tacts are facing up (the blue insulation should
be facing down).
c Lock the connector by pushing in on the locking mechanism.
NOTE: Intermittent display problems may result if W10 is not connected correctly.
• Torque W9 to 9 in-lbs.
• Torque all T-10 TORX screws to 9 in-lbs.
• Torque all T-15 TORX screws to 21 in-lbs.
