6-9
Error Messages
Command Error
-104 Data type error
The parser recognized a data element that is not allowed. For example, numeric or string
data was expected, but block data was encountered.
-105
GET not allowed
A Group Execute Trigger was received within a program message (see IEEE 488.2, 7.7).
Correct the HP-IB controller program so that the
GET does not occur within a line of
HP-IB program code.
-108
Parameter not allowed
More parameters were received than expected for the header. For example, the *ESE
common command only accepts one parameter, so receiving
*ESE 0,1 is not allowed.
-109
Missing parameter
Fewer parameters were received than required for the header. For example, the *ESE
common command requires one parameter, so receiving
*ESE is not allowed.
-110
Command header error
An error was detected in the header. This message is used when the device cannot detect
the more specific errors described for errors
111 through 119.
-111
Header separator error
A character which is not a legal header separator was encountered while parsing the
header.
-112
Program mnemonic too long
The header contains more than twelve characters (see IEEE 488.2, 7.6.1.4.1).
-113
Undefined header
The header is syntactically correct, but it is undefined for this specific device. For
example,
*XYZ is not defined for any device.
-114
Header suffix out of range
The value of a header suffix attached to a program mnemonic makes the header invalid.
-120
Numeric data error
This error, as well as errors 121 through 129, are generated when parsing a data
element which appears to be numeric, including non-decimal numeric types. This
particular error message is used if the device cannot detect a more specific error.
