Agilent Technologies ESG-D Series User Manual

A12 SYNTH/DOUBLER BLOCK DIAGRAM
A12 SYNTH/DOUBLER BLOCK DIAGRAM
Φ
ABUS
ABUS
ABUS
VCO TUNE
3 T0 32.2V
500-1000 MHz
LOOP GAIN
SYNTHESIZER
DAC
Loop Filter
&
Lead/Lag
OUT OF LOCK
DETECTOR
VCO
Frac-N
Divide
+10 V
2
5 MHz
LOOP
0.02 to -10.1 V
VCO FM
(NOT USED)
10 MHz SYNTH
P3-15
FROM REFERENCE ASSY
P1-6
LOCK ANGLE
ADJUSTMENT
F/2
VCO
BIAS
LOOP BW
CONTROL
DIVIDE-BY-2
2
250-500 MHz
500-1000 MHz
BANDPASS FILTERS
628-1000 MHz
396-628 MHz
250-396 MHz
X2
1ST DOUBLER
1.6-2.0 GHz
1.26-1.6 GHz
1-1.26 GHz
X2
2ND DOUBLER
3.2-4.0 GHz
2.52-3.2 GHz
2.0-2.52 GHz
FROM OUTPUT ASSY
P3-4
P3-17
>2 GHz TO 4 GHz
250 MHz TO 1000 MHz
>1 GHz TO 2 GHz
PRE-LEVEL MOD DRIVE
PRE-LEVEL
MOD
ABUS
RF OUT
RF OUT
250 MHz TO 4GHz
> +10 dBm
J6
_
TO OUTPUT ASSY
J4
-0.45 TO -0.7V
OUTPUT
ABUS
FM
3
DAC
DAC
FM
DELAY
A/D
CONVERTER
FM
ATTENUATORS
FM INPUT
FM IN-BAND
FM OUT-OF-BAND
DIGITAL INTERFACE
FROM MOTHERBOARD/CPU ASSY
J5-23
FROM MOTHERBOARD/CPU ASSY
J5-20
FROM MOTHERBOARD/CPU ASSY
J5-26
SERIAL I/O
INT 1
INT 2
INT 3
INT 4(SERIAL DATA)
CLK
DATA
ENABLE/INTERRUPT
CLK
DATA
ENABLE/INTERRUPT
L_OUT OF LOCK
NOT USED
NOT USED
SER_DATA_OUT
(FRAC-N DIVIDER)
CLK
SELECT
DATA
EEPROM
P2-24
P2-25
P2-11
DIGITAL
CONTROL
ABUS
POWER SUPPLY INPUTS
REG
+10V
P2-5,20
P2-14,29
P2-4,19
P2-3,18
P2-2,17
P2-1,16
P2-15,30
+15V
+10V
9.9 T O 10.1V
+32V
+10V
+9V
+5.2V
-5.2V
-6V
-15V
ANALOG COMMON
DIGITAL COMMON
P2-7
P2-6,21
MOD_STRB
P1-20
FROM MOTHERBOARD/
CPU ASSY
J5-54
FM INPUT
P1-1
FROM REFERENCE ASSY
P3-11
sk792a
