3-10
Replaceable Parts
Major Assemblies
Top View
A7 E4400-60005 1 Bd Assy-Baseband Generator (Option 1EH)
A7 E4400-69005 Exchange Bd Assy-Baseband Generator (Option 1EH)
A7 E4400-60048 1 Bd Assy-Baseband Generator (Options UN3, UN4)
A7 E4400-69048 Exchange Bd Assy-Baseband Generator (Options UN3, UN4)
A8 E4400-60043 1 Bd Assy-Data Generator, 1 Meg (Option UN3)
A8 E4400-69043 Exchange Bd Assy-Data Generator, 1 Meg (Option UN3)
A8 E4400-60057 1 Bd Assy-Data Generator, 8 Meg (Option UN4)
A8 E4400-69057 Exchange Bd Assy-Data Generator, 8 Meg (Option UN4)
A14 E4400-60001 1 Bd Assy-CPU/Mother
A14 E4400-69001 Exchange Bd Assy-CPU/Mother
A14BT1 1420-0338 1 Battery-Lithium
AT1 E4400-60007 1 Assy-Electronic Attenuator/RPP
AT1 E4400-69007 Exchange Assy-Electronic Attenuator/RPP
B1 3160-1040 1 Assy-Fan, Small
B2 E4400-60062 1 Kit-Fan, Large (includes 2 foam strips)
Top View
Reference
Designator
HP Part Number Qty Description
To Next Page
