3-25
Replaceable Parts
Cables
Top View (Option 1EH/1EM)
Reference
Designator
HP Part Number Qty Description
A4W1
1
1. This cable is not replaceable by itself. You must order the corresponding assembly.
(part of A4) 1 Power Supply (A4) to CPU/Motherboard (A14J6)
A16W1
1
(part of A16) 1 Line Module (A16) to Power Supply (A4J1)
A16W2
1
(part of A16) 1 Line Module (A16) to Chassis Ground Post on Rear Panel
A17W1
1
(part of A17) 1 Rear Panel Interface Board (A17) to Baseband Generator (A7P300)
W1 8120-6839 1 I IN to Daughterboard (A15J2)
W2 8120-6839 1 Q IN to Daughterboard (A15J3)
W3 8120-5143 1 DATA to Baseband Generator (A7P100)
W4 8120-5143 1 DATA CLOCK to Baseband Generator (A7P103)
W5 8120-5143 1 SYMBOL SYNC to Baseband Generator (A7P101)
W6 8120-6839 1 EXT 1 to Daughterboard (A15J4)
W7 8120-6839 1 EXT 2 to Daughterboard (A15J5)
W8 8120-6839 1 LF OUTPUT to Daughterboard (A15J6)
W9 E4400-20025 1 RF OUTPUT to Electronic Attenuator/RPP (AT1)
W11 E4400-60059 1 Output Board (A9) to Synthesizer/Doubler Board (A12) (includes cable retainer and ring)
W12 E4400-60060 1 Output Board (A9) to COHERENT CARRIER (includes cable retainer and ring)
W13 8120-6837 1 Electronic Attenuator/RPP (AT1) to CPU/Motherboard (A14J14)
W14 E4400-60061 1 Electronic Attenuator/RPP (AT1) to Output Board (A9) (includes cable retainer and ring)
W15 8120-5143 1 Baseband Generator (A7P403) to 13 MHz
W16 8120-5143 1 Baseband Generator (A7P404) to Q OUT
W17 8120-5143 1 Baseband Generator (A7P405) to I OUT
