Agilent InfinityLab LC Series VWD User Manual 154
10 Parts and Materials for Maintenance
Semi-micro Flow Cell (Parts)
Semi-micro Flow Cell (Parts)
The semi-micro #1 and #2 gaskets (items 6 and 7) look very similar. Do not mix
them up.
Item p/n Description
G1314-60183 Semi-micro flow cell 6 mm, 5 µL
(with RFID tag)
5021-1823 Capillary column – detector SST 400 mm lg, 0.12 mm i.d.
1 G1314-20047 Cell screw
G1314-65056 Semi-micro cell kit, includes two quartz windows, one gasket #1, one
#2 and two PTFE gaskets.
2 79853-29100 Conical spring kit, 10/pk
3 79853-22500 Ring SST, 2/pk
4 79853-68743 PTFE gasket (round hole i.d. 2.5 mm, o.d. 8 mm), (10/pk)
5 79853-68742 Window quartz kit, 2/pk
6 Semi-micro #1 gasket (long hole 1.5 x 3.5 mm), PTFE
7 Semi-micro #2 gasket (long hole 2 x 4 mm), PTFE
8 G1314-44010 Clip for RFI ID tag
9 0515-4780 Screw for Clip, M2.2, 4.5 mm long
