Agilent InfinityLab LC Series VWD User Manual 161
11 Identifying Cables
Cable Overview
RS-232 cables
(not for
FUSION board)
USB cables
p/n Description
RS232-61601 RS-232 cable, 2.5 m
Instrument to PC, 9-to-9 pin (female). This cable has special pin-out, and is not
compatible with connecting printers and plotters. It is also called "Null Modem
Cable" with full handshaking where the wiring is made between pins 1-1, 2-3,
3-2, 4-6, 5-5, 6-4, 7-8, 8-7, 9-9.
5181-1561 RS-232 cable, 8 m
p/n Description
5188-8050 USB A M-USB Mini B 3 m (PC-Module)
5188-8049 USB A F-USB Mini B M OTG (Module to Flash Drive)
