Page #254 background image
254 Agilent InfinityLab LC Series 1260 Infinity II FLD User Manual
12
Hardware Information
Interfaces
Special Interfaces
There is no special interface for this module.
Table 31 ERI signal distribution
Pin Signal Description
1 START REQUEST (L) Request to start injection cycle (for example, by start key on
any module). Receiver is the autosampler.
2 STOP (L) Request to reach system ready state as soon as possible (for
example, stop run, abort or finish and stop injection). Receiver is
any module performing run-time controlled activities.
3 READY (H) System is ready for next analysis. Receiver is any sequence
controller.
4 POWER ON (H) All modules connected to system are switched on. Receiver is
any module relying on operation of others.
5Not used
6 SHUT DOWN (L) System has serious problem (for example, leak: stops pump).
Receiver is any module capable to reduce safety risk.
7 START (L) Request to start run / timetable. Receiver is any module
performing run-time controlled activities.
8 PREPARE (L) Request to prepare for analysis (for example, calibration,
detector lamp on). Receiver is any module performing
pre-analysis activities.
