Setting Up the Oscilloscope
This chapter shows you how to set up your Infiniium oscilloscope, connect power and
accessories, and verify general operation.
To inspect package contents
❏ Inspect the shipping container for damage.
Keep a damaged shipping container or cushioning material until you have inspected the contents
of the shipment for completeness and have checked the oscilloscope mechanically and
electrically.
❏ Verify that you received the following items in the Infiniium Oscilloscope packaging.
• Infiniium Oscilloscope
• Mouse, Agilent part number 1150-7913
• Stylus, Agilent part number 1150-7997
• Keyboard, Agilent part number 1150-7809
• Accessory Pouch, Agilent part number 54810-68701
• Front-panel Cover, Agilent part number 54810-42201
• Calibration Cable Assembly, Agilent part number 54855-61620
• Precision 3.5 mm Adapters (quantity 2), Agilent part number 54855-67604
• Probe De-skew and Performance Verification Kit, Agilent E2655B
• Power Cord (see chapter 6, “Replaceable Parts,” for available power cords)
• User's Quick Start Guide
The Programmer’s Guide and this Service Guide are included on the oscilloscope’s hard drive.
See Figure 2-1. (See table 2-4 for the power cord.) If anything is missing, contact your nearest
Agilent Technologies Sales Office. If the shipment was damaged, contact the carrier, then contact
the nearest Agilent Technologies Sales Office.
❏ Inspect the oscilloscope.
• If there is mechanical damage or a defect, or if the oscilloscope does not operate properly or
does not pass performance tests, notify your Agilent Technologies Sales Office.
• If the shipping container is damaged, or the cushioning materials show signs of stress, notify
the carrier and your Agilent Technologies Sales Office. Keep the shipping materials for the
carrier’s inspection. The Agilent Technologies Sales Office will arrange for repair or
replacement at Agilent’s option without waiting for claim settlement.
❏ Verify that you received the options and accessories you ordered and that they are not
damaged.
