Agilent Technologies Infiniium 80000 Series User Manual

Chapter 7: Replaceable Parts
Replaceable Parts List
143
Replaceable Parts List
The following table is a list of replaceable parts and is organized as follows:
• Exchange assemblies in alphanumeric order by reference designation.
• External chassis parts in alphanumeric order by reference designation. These parts are
generally those that take the physical wear and tear of use.
• Internal parts in several categories. Each category is in alphanumeric order by reference
designation. Replacing these parts generally requires opening the cabinet.
The information given for each part consists of the following:
• Reference designation.
• Agilent Technologies part number.
• Total quantity (QTY) in oscilloscope or on assembly. The total quantity is given once and at
the first appearance of the part number in the list.
• Description of the part.
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
A1 Repair Center
Replacement
Only
1
4-CH ACQUISITION ASSEMBLY (Agilent Model DSO80204B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO80304B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO80404B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO80604B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO80804B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO81004B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO81204B)
A1 Repair Center
Replacement
Only
1 4-CH ACQUISITION ASSEMBLY (Agilent Model DSO81304B)
A2 54857-62601 1 POWER SUPPLY SUBASSEMBLY
A4 0960-2522 1 CD ROM ADAPTER BOARD (NOT ON OPTION 017)
A5 0950-4635 1 INVERTER BOARD
A6 0950-4741 1 CD ROM R/W
A8 1 HARD DRIVE w/SOFTWARE (NOT ON OPTION 017)
A9 54810-66506 1 PROBE INTERFACE BOARD
A10 0960-2530 1 DISPLAY BOARD
A11 54858-66513 1 USB TOUCHSCREEN CONTROLLER BOARD, PROGRAMMED
A13 2090-0911 1 XGA DISPLAY
A16 54857-68803 1 PROBE INTERFACE KIT
A17 54826-66507 1 KEYBOARD - CURSOR
A18 54832-66504 1 MAIN KEYBOARD
A19 D81004-68809 1 MOTHERBOARD SUBASSEMBLY
A21 54855-66515
1
INTERFACE & GPIB BOARD
