Chapter 7: Replaceable Parts
Replaceable Parts List
144
A23 54857-66502
1
POWER DISTRIBUTION BOARD
B1 3160-4134 6 12 V FAN
H1 0515-2219 3 SCREW-MACHINE M2.5 X 0.45; 5 MM-LG; T8 ; RECESS, 90 DEGREE FLAT
H2 54503-25701 5 HEX NUT BNC
H3 0515-1025 4 SCREW-MACHINE M3.0 X 0.50; 26 MM-LG; T10; RECESS; WASHER
H4 0515-1410 6 SCREW-MACHINE M3.0 X 0.50; 20 MM-LG; T10; RECESS, PAN; WASHER
H6 0515-0372 22 SCREW-MACHINE M3 X 0.5 8 MM-LG; T10; RECESS; WASHER
H7 0515-1246 2 SCREW-MACHINE; M3.0 X 0.50; 6 MM-LG; T10; RECESS, PAN; PATCH LOCK
H8 5021-4302 2 SCREW MACHINE M4X0.7 20MM-LG
H9 54801-24702 2 SPACER-STRAP HANDLE
H10 0515-2195 8 SCREW-MACHINE M4.0 X 0.70; 40 MM-LG; T20; RECESS, PAN; WASHER
H11 0515-1103 10 SCREW-MACHINE M3.0 X 0.50; 10 MM-LG; T10; RECESS, 90 DGR-FLT
H11 0515-1103 10 SCREW-MACHINE M3.0 X 0.50; 10 MM-LG; T10; RECESS, 90 DGR-FLT
H12 0515-0380 18 SCREW-MACHINE M4.0 X 0.70; 10 MM-LG; T20; RECESS, PAN; WASHER
H12 0515-0380 18 SCREW-MACHINE M4.0 X 0.70; 10 MM-LG; T20; RECESS, PAN; WASHER
H13 0515-1403 4 SCREW-SPCL M4 X 0.7; 6 MM-LG; 90-DEG-FLH-HD
H15 0515-0375 3 SCREW-MACHINE ASSEMBLY M3 X 0.5 16MM-LG
H16 0515-0365 5 SCREW-MACHINE M2 X 0.4; 4 MM-LG
H20 2190-0027 1 WASHER-LK INTL T 1/4 IN .256-IN-ID
H21 0515-0436 4 SCREW-MACH M4.0 X 0.70; 18 MM-LG; T20; WASHER (NOT ON OPTION 017)
H22 0515-0374 4 SCREW-MACH; M3.0 X 0.50; 10 MM LONG; T10; WASHER
H24 0515-1940 4 SCREW-MACH; M2.5 X 0.45; 6 MM LONG; T8; LOCK
H25 0515-0666 10 SCREW-MACHINE M3.0 X 0.50; 18 MM-LG; T10; RECESS, PAN; WASHER
H26 0515-0368 16 SCREW-MACHINE M2.5 X 0.45; 12 MM-LG; T8; RECESS; WASHER
H27 2950-0054 2 NUT 1/2-28 THD
H28 2190-0068 2 WASHER-LK INTL T 1/2 IN .505-IN-ID
H31 0515-0383 4 SCREW-MACH M4 X 0.7; 16 MM-LG; T20 REC;WASHER (not on option 017)
H33 0515-0456 1 SCREW-MACHINE M4 X 0.7; 20 MM-LG; T20 RECESS; WASHER
H34 0515-0664 9 SCREW-MACHINE M3 X 0.5; 16 MM-LG PAN-HD
MP1 0624-1066 24 FAN SCREWS
MP2 D8104-00501 1 SLEEVE BOTTOM
MP3 D8104-60101 1 CHASSIS ASSEMBLY
MP4 D8104-60102 1 ATX TRAY
MP5 54857-01211 1 HARD DRIVE BRACKET (NOT ON OPTION 017)
MP7 D8104-01201 1 CD ROM MOUNT BRACKET
MP8 D8104-04103 1 FRONT FRAME BACK PLATE
MP9 D8104-40501 1 FRONT FRAME
MP12 D8104-01205 1 LENS BRACKET
MP13 54801-47403 1 KNOB 24 MM GRAY
MP14 54801-47408 1 KNOB 18 MM YELLOW
MP15 54801-47404 1 KNOB 12 MM YELLOW
MP16 54801-47409 1 KNOB 18 MM GREEN
MP17 54801-47405 1 KNOB 12 MM GREEN
MP18 54801-47410 1 KNOB 18 MM PURPLE
MP19 54801-47406 1 KNOB 12 MM PURPLE
MP20 54801-47411 1 KNOB 18 MM PINK
MP21 54801-47407 1 KNOB 12 MM PINK
MP22 54801-47401 2 KNOB 12 MM GRAY
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
To Next Page
