Agilent Technologies Infiniium 80000 Series User Manual

Chapter 7: Replaceable Parts
Replaceable Parts List
145
MP23 54801-24701 1 BRACKET STIFFENER
MP25 54801-09101 2 SPRING, STEEL 1095
MP26 54857-68804 1 SUBASSEMBLY FRONT PANEL
MP27 54857-41901 1 MAIN KEYPAD
MP29 54810-41902 1 CURSOR KEYPAD
MP31 54810-68701 1 ACCESSORY POUCH
MP32 5042-1798 2 REAR FEET
MP33 54810-04104 1 SLEEVE TOP
MP34 54810-44901 1 MOLD OVER HANDLE
MP35 54810-45001 2 END CAP HANDLE
MP36 54810-61001 4 BOTTOM FEET w/INSERT
MP37 54810-03702 1 TILT STAND
MP38 01680-41002 4 SIDE FOOT
MP39 1520-0238 4 GROMET (NOT ON OPTION 017)
MP40 D8104-94302 1 USB LABEL (not shown)
MP42 1400-3242 1 CABLE CLAMP
MP43 54852-94309 1 LOGO LABEL/DSO80204B
MP43 54853-94309 1 LOGO LABEL/DSO80304B
MP43 54854-94309 1 LOGO LABEL/DSO80404B
MP43 54855-94309 1 LOGO LABEL/DSO80604B
MP43 54856-94309 1 LOGO LABEL/DSO80804B
MP43 54857-94309 1 LOGO LABEL/DSO81004B
MP43 54858-94309 1 LOGO LABEL/DSO81204B
MP43 54859-94309 1 LOGO LABEL/DSO81304B
MP44 54857-60201 1 ATX PANEL COVER
MP45 54810-42204 1 GROMMET 9x64
MP47 54810-42202 1 GROMMET 20x50
MP48 54855-61101 4 HEAT SINK
MP49 54857-60201 1 REMOVEABLE HARD DRIVE COVER PLATE (NOT ON OPTION 017)
MP50 54857-01216 1 REMOVEABLE HARD DRIVE BRACKET (OPTION 017 ONLY)
MP51 54857-01213 1 POWER SUPPLY BRACKET
MP52 54857-01215 2 SUPPORT BRACKET
MP53 54857-61201 1 PROBE COMP PLATE
W3 54826-61606 1 ACQUISITION SIGNAL CABLE
W4 D8104-61601 1 POWER HARNESS CABLE
W5 54855-61621 1 POWER INPUT/LINE SINC
W6 54810-61613 1 CABLE ASSEMBLY POWER SUPPLY
W7 54855-61624 1 MOTHERBOARD SWITCH CABLE
W8 54810-61606 1 AUTO PROBE INTERFACE CABLE
W11 54857-61613 1 DISPLAY CABLE
W12 54855-61602 1 KEYBOARD CABLE
W14 54810-61615 1 HARD DRIVE GROUND CABLE (NOT ON OPTION 017)
W15 D8104-61603 2 SATA HDD CABLE
W17 54855-61608 1 PROBE POWER CABLE
W18 8120-1703 1 CABLE-POWER (Option 900-UK)
W18 8120-0696 1 CABLE-POWER (Option 901-AUSTL)
W18 8120-1692 1 CABLE-POWER (Option 902-EUR)
W18 8120-2296 1 CABLE-POWER (Option 906-SWIT)
W18 8120-2957 1 CABLE-POWER (Option 912-DEN)
W18 8120-4600 1 CABLE-POWER (Option 917-AFRICA)
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
