4
80000 Series Oscilloscope Rear Panel
Note: Your instrument’s rear panel configuration may differ from this diagram.
LAN
Port
GPIB Interface
Mouse
and
Keyboard
Ports
Video
Output
CD-ROM
Drive
USB
Ports
Line In
Line Out
Microphone
TTL
Trig
Out
AC Power
Input
Aux
Trig
In
Parallel
Printer
Port
RS232
COM
Port
Rear
Foot
Kensington
Equipment
Lock
Optional
Removable
Hard Drive
10 MHz
Ref In
10 MHz
Ref Out
