Agilent Technologies Infiniium 80000 Series User Manual

Chapter 5: Troubleshooting
Primary Trouble Isolation
70
Primary Trouble Isolation Flowchart (Part 2 of 2)
Check front panel
response.
Do
knob and key test
OK?
System works; do
performance tests
End
Go to 'Front Panel
Trouble Isolation'
Does
LED test
OK?
Check calibration
Does
self calibration test
pass?
Go to 'Acquisition
Trouble Isolation'
No
No
Yes
E
F
G
Yes
Run scope self tests.
Does
self test
pass?
D
Go to 'Acquisition
Trouble Isolation'
No
Yes
Yes
PT
