Agilent Technologies Infiniium 80000 Series User Manual

Chapter 5: Troubleshooting
Motherboard Verification
92
Check that the motherboard switch cable
is seated properly.
No
Is
cable
OK?
No
Use tweezers to short the reset pins
together.
Do fans
turn on & does
motherboard beep
(@10 sec)?
Yes
Go to 'Front Panel
Button Debug'.
Remove all PCI cards and disconnect
hard drive, CD drive and floppy drive
from the motherboard.
Use tweezers and motherboard switch
cable to try and get the motherboard to
boot.
Start adding components back in one at
a time. Remove all cables from cards and
add them back on one at a time also
Go to 'Primary
Trouble Isolation'.
Motherboard verification
Do fans
turn on & does
motherboard beep
(@10 sec)?
No
Yes
A
Replace motherboard if
all components removed
& motherboard still does
not boot.
No
See Figure 5-15.
