34 Advisor Mainframe Features System Guide
4 Attaching/Removing Undercradles
3 Insert the connector board into the slot uncovered by the
metal plate.
4 Make sure all four silver tabs on the top of the undercradle
are pulled out.
5 Place the mainframe on top of the undercradle, matching the
connector on the bottom of the mainframe to the connector
on the top of the undercradle.
6 Push in the four silver tabs, locking the undercradle to the
mainframe.
Removing an Undercradle
1 Turn off the power and unplug the Advisor.
2 Pull out the four silver tabs on the front and the back of the
undercradle.
3 Lift the Advisor away from the undercradle.
Silver Tabs
