66 Advisor Mainframe Features System Guide
B Breakout Box, LEDs, and Connectors
V-Series Interfaces
The V-Series Interfaces are the RS-232, RS-449, and V.35
interfaces. The following signals are analyzed on the V-Series
Interfaces:
V-Series
Functions
V-Series
Functions for
High Speed
External Pods
Only
Function RS-232 V.35 RS-449
Send Data DTE SD SD
Receive Data DCE RD RD
DTE/Send Timing (DCE) TC SCT ST
DCE/Receive Timing (DCE) RC SCR RT
DTE/Send Timing (DTE) ETC SCE TT
Request to Send RTS RS RS
Clear to Send CTS CS CS
Data Terminal Ready DTR DTR TR
Data Set/Mode Ready DSR DSR DM
Carrier Detect/Rec. Ready CD CD RR
Function RS-232 V.35 RS-449
Local Loopback (Drv) LLB LLB
Remote Loopback (Drv) RLB RLB
Test Mode (Mon) TM TM
