54 Advisor Mainframe Features System Guide
A Specifications
J2300D/E Specifications
Refer to Appendix B for connector pinouts.
MIC
F
EXT
Left Side of J2300D/E Advisor
MONITOR
SERIAL PORT
A
B
C
RS-232
RS-232
D
PARALLEL
PORT
PHONES
G
H
E
Front
A On-Off Switch
B Power cable receptacle
C Two RS-232/V.24 connectors
D Parallel Port
E External Monitor
F Serial Port
G Headphones
H Microphone
