Agilent Technologies J2300D User Manual

Breakout Box, LEDs, and Connectors B
Advisor Mainframe Features System Guide 69
V.35
Pin Circuit Name
A Chassis Ground
B Signal Ground
C Request to Send
DClear to Send
E Data Set Ready
F Receive Line Signal Detect
P Transmit Data (A)
R Received Data (A)
S Transmit Data (B)
T Received Data (B)
U Terminal Timing (A)
V Receive Timing (A)
W Terminal Timing (B)
X Receive Timing (A)
Y Transmit Timing (A)
AA Transmit Timing (B)
