2 General Power Meter Functions
102 N1913/1914A EPM Series Power Meters User’s Guide
Setting the Cable Short/Long
When connecting the power sensor with Agilent 11730F power sensor
cable, 61 m (200 ft), you are required to change the cable setting from
Short (default setting) to Long, or an error will occur when the power
sensor is connected.
To access the cable setting,
1 Press , and select .
2 In the Service menu, press and select to toggle
between the short or long cable option.
The LCB indicator will appear in blue at the bottom of the display to
indicate that the long cable option is selected as shown in Figure 2- 67.
Figure 2-67 Short/long cable option
