General Power Meter Functions 2
N1913/1914A EPM Series Power Meters User’s Guide 75
Saving and Recalling Power Meter States
To reduce repeated setup sequences, you can save a maximum of ten
power meter states in the non- volatile memory.
The save/recall functions are part of the Sys/Inputs menu, accessed by
pressing the key.
To save a measurement setup:
1 Press , to display the Save/Recall screen as shown in
Figure 2- 37.
Figure 2-37 Save/Recall screen
2 Using the and keys, select an available name from the
displayed list. To change the name of a register - See Chapter 2,
“Editing a Register’s Name,” starting on page 76, otherwise press .
3 The power meter prompts you to press to proceed.
Figure 2-38 Save confirm pop-up
