Specifications and Characteristics 10
Agilent N1913/1914A EPM Series Power Meters User’s Guide 233
Rear Panel Inputs and Output Connections
Line Power
Recorder Output(s) Analog 0 to 1 V, 1 kW output impedance, BNC connectors
GPIB
USB 2.0
10/100BaseT LAN
Interfaces allow communication with an external controller
Trigger Input (Optional) Input has TTL compatible logic levels and uses a BNC
connector
Trigger Out (Optional) Output provides TTL compatible logic levels and uses a BNC
connector
Ground Binding post, accepts 4 mm plug or bare wire connection
USB Host (Optional) To connect U2000 Series USB power sensors
VGA Out (Optional) Standard 15-pin VGA connector, allows connection of
external VGA monitor
Input Voltage Range 100 to 240 Vac
100 to 120 Vac
Automatic voltage selection
Fluctuations not exceeding ±10%
Input Frequency Range 50 to 60 Hz (100 to 240 Vac)
400 Hz (100 to 120 Vac)
Power Requirement 70 VA (maximum)
