2 General Power Meter Functions
82 N1913/1914A EPM Series Power Meters User’s Guide
Table 2 - 5 Power Sensor Connection Requirements
Sensor Model Connection Requirements
Agilent 8481A
Agilent 8481H
Agilent 8482A
Agilent 8482H
Agilent N8481A
Agilent N8482A
Agilent E4412A
Agilent E930xA
Agilent E930xH
Agilent E9304 H18
Agilent E9304 H19
These power sensors connect directly to the reference calibrator.
Agilent 8481D
Agilent 8484A
Prior to the power meter being calibrated, an Agilent 11708A 30 dB
reference attenuator should be connected between the power sensor
and the reference calibrator. Remove this attenuator from the power
sensor input before making measurements.
Agilent 8483A This power sensor requires a 75 Ω (f) to 50 Ω (m) N-Type adapter
(1250-0597) to connect to the reference calibrator. Remove this
adapter from the power sensor input before making measurements.
Agilent R8486A
Agilent Q8486A
Agilent V8486A
Agilent W8486A
Agilent R8486D
Agilent Q8486D
The waveguide power sensors have two connectors. The N-Type
connector is the one which is used to calibrate the power meter.
Agilent 8481B
Agilent 8482B
Agilent E930xB
These power sensors are configured with an attenuator. Prior to the
power meter being calibrated, this attenuator must be removed. The
attenuator must be reconnected prior to making measurements.
Agilent 8485A
Agilent N8485A
Agilent E4413A
Agilent E9300A H24
Agilent E9300A H25
This power sensor requires an APC 3.5 (f) to 50 Ω (m) N-Type adapter
(08485-60005) to connect to the reference calibrator. Remove this
adapter before making measurements.
