Introduction 1
Agilent N1913/1914A EPM Series Power Meters User’s Guide 27
Making Socket Connection
The power meter can be remotely connected via socket connection. To
connect the meter using socket connection,
1 Right- click the Agilent IO Libraries icon on the taskbar and select
Agilent Connection Expert.
2 On the Agilent Connection Expert window, click on . An
Add Instrument window will be prompted out. Select Add LAN instrument
on LAN (TCPIPO) interface and click OK (see Figure 1- 11).
Figure 1-11 Add Instrument window
3 On the Add LAN Instruments window (see Figure 1- 12), click the Add
Address.
4 Select the Use IP Address option and type the IP address. Select the Use
socket connection.
5 Click Test Connection to test if the instrument is present.
6 Click OK. You will then return to the Agilent Connection Expert window
(see Figure 1- 13). Your meter is successfully connected via socket
connection.
