2 General Power Meter Functions
56 N1913/1914A EPM Series Power Meters User’s Guide
Figure 2-20 Channel Setup display
4 Press . The Trigger menu is displayed.
5 Press softkey to configure the trigger.
6 Select either or .
• is a single shot mode. After triggering, the measurement is
halted, and the symbol is displayed. You can start another
measurement by pressing the key.
• is a continuous trigger mode. The symbol or is
displayed.
7 Press to configure the remaining trigger parameters. The trigger
Settings menu consists of two pages. Figure 2- 21 shows page 1 and
Figure 2- 22 shows page 2.
When 8480 Series, N8480 Series, E-Series E4410, E-Series E9300 or U2000 Series sensor is
connected, Sensor Mode is set to AVG only by default.
