General Power Meter Functions 2
N1913/1914A EPM Series Power Meters User’s Guide 67
Single Function Measurement
Figure 2- 27 shows an average measurement assigned in the upper
measurement line of the upper window. (For single channel power meter,
N1913A, the Channel field will be disabled, as shown in Figure 2- 27).
1 Use the , , , , to highlight the Combination function field.
2 Press to display the Function pop- up, and use the and
to highlight Single.
Figure 2-28 Function pop-up
3 Press to complete the entry.
4 The Meas field is set to Avg by default.
5 Press key to complete the setup and display the measurement
results.
The gate field is disabled if trigger acquisition is Free Run.
