2 General Power Meter Functions
60 N1913/1914A EPM Series Power Meters User’s Guide
10 Press or to setup measurement settings such as
measurement averaging, measurement frequency, offsets, duty cycle and
so forth. Refer to “General Power Meter Functions” on page 31 for the
setup procedures.
11 Set the frequency range and step by sending the below commands to
meter using remote interface.
• SENSe1:FREQuency:STARt
<start_frequency><frequency_unit>
• SENSe1:FREQuency:STOP <stop_frequency><frequency_unit>
• SENSe1:FREQuency:STEP <frequency_step_size>
12 Send *OPC (OPeration Complete) command to meter; to set the
operation complete bit in the Standard Event Status register when all
pending device operations are completed.
13 Set the meter to continuous trigger cycles by sending
INITiate:CONTinuous ON command to meter.
14 Configure and set the required power sweep range and step of the
power source.
15 Set the power source trigger input and trigger output.
16 Set the power source to sweep.
Refer to the EPM Series Power Meters Programming Guide for the commands usage
details.
Example of commands set:
FREQ:STAR 10MHz
FREQ:STOP 500MHz
FREQ:STEP 10
The power meter can be remotely controlled by LAN, USB and GPIB (IEEE488)
programming interfaces. Refer to N1913/1914A EPM Series Power Meters Installation
Guide for details.
