Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Troubleshooting
Troubleshooting Unlevels
1-67
• If the signal generator is an N5181A and it does not meet the listed power level in Table 1-10, proceed to “Troubleshooting the RF Path
(N5161A/62A/81A/82A)” on page 1-68.
• If the signal generator is an N5162A/82A and does not achieve the maximum power levels listed in Table 1-10, perform the following
procedure:
Press
1.
Mode > Dual Arb > Arb Off/On - until Off is highlighted
2. Press
Mode > Real Time I/Q Baseband AWGN > Real-time AWGN Off/On - until Off is highlighted
Table 1-10N5181A/82A Output Power
Frequencies Output Power (All Instruments with
serial prefixes <4740 and without
Option 099 or Option 01K.)
Output Power (All Instruments with
serial prefixes >
4740 or all instruments
with Option 01K.)
100 kHz to <250 kHz N/A +4 dBm
≥250 kHz to 2.5 GHz +13 dBm +13 dBm
>2.5 GHz to 3.0 GHz +10 dBm +10 dBm
>3.0 GHz to 4.5 GHz +13 dBm +13 dBm
>4.5 GHz to 5.8 GHz +10 dBm +10 dBm
>5.8 GHz to 6 GHz +7 dBm +7 dBm
Table 1-11 N5161A/62A/81A/62A/82A Output Power
a
a
All instruments with serial number > xx4818xxx and all
instruments with serial number < xx4818xx with Option 099.
Frequencies Output Power
100 kHz to 50 MHz +13 dBm
>50 MHz to 3 GHz +13 dBm
>3.0 GHz to 5.0 GHz +13 dBm
>5.0 GHz +11 dBm
Table 1-12N5183A Output Power
Frequencies Output Power N5183A
with Opt 520
Output Power N5183A
with Opt 520 and Opt
1EA
Output Power N5183A
with Opt 532 and Opt
540
Output Power N5183A
with Opt 532, Opt 540,
and Opt 1EA
100 kHz to 250 kHz +11 dBm +14 dBm +11 dBm +14 dBm
>250 kHz to 3.2 GHz +11 dBm +15 dBm +7 dBm +15 dBm
>3.2 GHz to 20 GHz +11 dBm +18 dBm N/A N/A
>3.2 GHz to 17 GHz N/A N/A +7 dBm +15 dBm
>17 GHz to 31.8 GHz N/A N/A +7 dBm +13 dBm
>31.8 GHz to 40 GHz N/A N/A +7 dBm +12 dBm
