5-8 Service Guide N5230-90014
Theory of Operation PNA Series Microwave Network Analyzers
Synthesized Source Group Operation N5230A
Table 5-2 Subsweep Frequencies
Band
A20
Mixer Brick
L.O.
Harmonic
A7 Frac-N
Synthesizer
Frequency
(GHz)
A6
Multiplier
Frequency
(GHz)
A9 Frac-N
Synthesizer
Frequency
(GHz)
A8
Multiplier
Frequency
(GHz)
A19
SSLAM
Frequency
(GHz)
0 1 0.008 to 0.009 0.008 to 0.009 .0003 to 0.001 .0003 to 0.001 .0003 to 0.001
1 1 0.009 to 0.018 0.009 to 0.018 0.001 to 0.010 0.001 to 0.010 0.001 to 0.010
2 1 0.018 to 0.048 0.018 to 0.048 0.010 to 0.040 0.010 to 0.040 0.010 to 0.040
3 1 0.048 to 0.756 0.048 to 0.756 0.040 to 0.748 0.040 to 0.748 0.040 to 0.748
4 1 0.756 to 1.508 0.756 to 1.508 0.748 to 1.500 0.748 to 1.500 0.748 to 1.500
5 1 1.508 to 3.133 1.508 to 3.133 1.500 to 3.125 1.500 to 3.125 1.500 to 3.125
6 1 1.566 to 2.087 3.133 to 4.174 1.563 to 2.083 3.125 to 4.167 3.125 to 4.167
7 1 2.087 to 2.629 4.174 to 5.258 2.083 to 2.625 4.167 to 5.250 4.167 to 5.250
8 1 2.629 to 3.129 5.258 to 6.258 2.625 to 3.125 5.250 to 6.250 5.250 to 6.250
9 1 1.564 to 2.085 6.258 to 8.341 1.563 to 2.083 6.250 to 8.333 6.250 to 8.333
10 1 2.085 to 2.627 8.341 to 10.508 2.083 to 2.625 8.333 to 10.500 8.333 to 10.500
11 3 1.751 to 2.085 3.503 to 4.169 2.625 to 3.125 5.250 to 6.250 10.500 to 12.500
12 3 2.085 to 2.251 4.169 to 4.503 1.563 to 1.688 6.250 to 6.750 12.500 to 13.510
