Service Guide N5230-90014 2-7
PNA Series Microwave Network Analyzers General Product Information
N5230A Required Service Test Equipment
Required Service Test Equipment
Microsoft® and Windows® are U.S. registered trademarks of Microsoft Corporation.
Equipment Critical Specifications
Recommended
Model or Part
Number
Alternate
Model or Part
Number
Use
a
a. P = Performance tests, A = Adjustments, T = Troubleshooting, V = System verification
Test Instruments and Software
Frequency counter
Freq: 10 MHz to 10.5 GHz
Accuracy : ±0.5 ppm
53151A
Opt 001
None P, A, T
Spectrum analyzer
Min Freq: 1 MHz
Max Freq: > 4 GHz
Resolution BW: 300 Hz
8565E
856xE A, T
Power meter Accuracy: ±0.0068 dB E4418B/19B
E4418A/19A
b
b. If an accurate measurement of the dynamic accuracy specification is not required, the E4418A or E4419A can
be used.
P, A , T
Power sensor
Freq: 300 kHz to 3.0 GHz
Range: –30 to +20 dBm
8482A
None
P, A , T
Power sensor
Freq: 3.0 GHz to 20 GHz
Range: –30 to +20 dBm
E4413A
None
P, A , T
Dynamic accuracy
test set
None specified
Z5623A
Opt H01
None P
Digital multi-meter
Voltage and resistance
measurement capability
Voltage resolution: 10 mV
Any Any T
Printer N/A
Any printer with Microsoft®
Windows® 2000 driver
P
Test software
c
c. The recommended model or part number for all equipment listed with a “P” in the Use column is required for
proper operation of this test software.
N/A N7840A None P
