2-8 Service Guide N5230-90014
General Product Information PNA Series Microwave Network Analyzers
Required Service Test Equipment N5230A
Required Service Test Equipment (Cont’d)
Equipment
a
a. Unless specified otherwise, equipment listed is required for all analyzer models.
Critical Specifications
Recommended
Model or Part
Number
Alternate Model
or Part Number
Use
b
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
Calibration and Verification Kits
3.5 mm calibration kit Freq: 10 MHz to 20 GHz 85052B 85052D P,T
3.5 mm verification kit Freq: 10 MHz to 20 GHz 85053B None V
Cables
BNC cable (2 required) 50Ω, length ≥ 60 cm 8120-1839 None A
3.5 mm RF cable (Qty 2) 50Ω, length ≥ 60 cm 85131C 85131E P,A,V
GPIB cable N/A 10833A/B/C/D None P,A
Adapters
3.5 mm (f) to 3.5 mm (f) Return Loss: ≥ 32 dB 83059B
85052-60012
c
c. Included in the 85052B/D calibration kits.
P, A, T
3.5 mm (f) to type-N (m) Return Loss: ≥ 28 dB 1250-1743 None P,A,T
Attenuators
3.5 mm (m,f), 10-dB fixed
attenuator
Accuracy: ± 0.5 dB
Freq: 10 MHz to 20 GHz
8493C
Option 010
None P
3.5 mm (m,f), 20-dB fixed
attenuator
Accuracy: ± 0.5 dB
Freq: 10 MHz to 20 GHz
8493C
Option 020
None P
