6-30 Service Guide N5230-90014
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230A
Rear Panel Assembly, All Options
Item
Number
Part
Number
Qty Description
➀
E8364-60023 1
Rear frame assembly (includes items
➁
–
➆
)
➁
E8356-00023 1 Cover plate, large
➂
6960-0149
5
Hole plug
➃
0515-0372 33 Machine screw, M3.0 x 8, pan head
➄
8120-5055 2 BNC cable assembly
➅
2950-0035 4
Hex nut (for BNC connector,
➄
and
➇
)
➆
2190-0102 4
Lock washer (for BNC connector,
➄
and
➇
)
➇
8120-5027 2 BNC cable assembly
➈
E8356-00022 1 Cover plate, digital section
➉
0515-0374 13
Machine screw, M3.0 x 10, pan head (to secure item )
N5230-00002 1 Test set motherboard rear panel (P/O A16)
85047-60005 2
Fuse holder (includes wire harness, nut, and washer)
a
a. See page 6-34 for the part number of the fuses.
1400-0112 2 Fuse holder cap
E8364-60095 1 Hard disk drive stationary board with mating connector
0515-1410 2
Machine screw, M3.0 x 20, pan head (to secure item )
11
11
12
13
14
15
14
