Page #131 background image
Service Guide N5230-90014 5-11
PNA Series Microwave Network Analyzers Theory of Operation
N5230A Synthesized Source Group Operation
A16 Test Set Motherboard
The A16 test set motherboard serves these functions:
to act as an interface between the A15 CPU board and the auxiliary rear panel
interconnects.
to provide ALC signals to the A19 SSLAM.
to route control signals to the signal separation group. Refer to “Signal Separation
Group Operation” on page 5-15 for more information.
Rear Panel Interconnects
The A16 test set motherboard includes the following rear panel interconnects.
TEST SET I/O A DB-25 female connector that is used to control external test sets. The
external test set bus consists of 13 multiplexed address and data lines, three
control lines, and an open-collector interrupt line. Pin assignments are
listed in Table 5-3 on page 5-12.
Up to 16 test sets may be “daisy-chained” on the bus at one time.
The Test Set I/O is not compatible with 8753 network analyzer test sets.
HANDLER I/O A rectangular 36-pin, female connector providing four independent parallel
input/output ports, nine control signal lines, one ground, and a power
supply line. This connector has Type 2 output pin assignments as listed in
Table 5-4 on page 5-13.
All signals are TTL-compatible. Data input/output ports consist of two 8-bit
output ports (Port A and Port B) and two 4-bit bidirectional ports (Port C
and Port D).
Connector settings can be changed using SCPI and COM commands. The
settings are not accessible from the front panel.
AUX I/O A DB-25 male connector that provides a variety of both analog and digital
input and output signals as described in Table 5-5 on page 5-14.
I/O 1 (TRIG IN) A BNC connector for input of an external trigger. The analyzer can be
triggered by an external device using this input. This is the same signal
that appears on AUX I/O pin 19 as described in Table 5-5 on page 5-14.
I/O 2 (TRIG OUT) A BNC connector for output of a trigger signal. This trigger signal can be
used to trigger external devices used in the measurement setup, such as
signal generators.
