Agilent Technologies N5230A User Manual

6-18 Service Guide N5230-90014
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230A
Bottom Assemblies, Active Configuration (Options F06 and F13
Combined with Options 014 and 1E1)
Reference
Designator
Part Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange Assemblies” on page 6-5.
Qty Description
A16 N5230-60078 1 Test set motherboard
A19
5087-7293
5087-6293
1 Switch/splitter/leveler/amplifier/multiplier (SSLAM)
A20
5087-7299
5087-6299
1 Mixer brick (QuintBrick)
A21
A22
5087-7301 2
Test port 1 coupler
Test port 2 coupler
A25
A26
33321-60065 2
Port 1 source step attenuator
Port 2 source step attenuator
A41 Hard disk drive. Refer to “Hard Disk Drive Assembly, All Options” on page 6-32.
➀
E8361-60059
1
USB hub board
➁
0960-0055
2
Termination, male SMA short circuit
