6-12 Service Guide N5230-90014
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230A
Top Cables, All Options
Reference
Designator
Type
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable; nR = n wires in a ribbon (flat) cable; nW = n wires in a wrapped cable
Part Number Qty Description
W1
SR N5230-20041
1
A7 fractional-N synthesizer board J106
to A6 multiplier board J100
W2 1
A7 fractional-N synthesizer board J101
to A6 multiplier board J101
W3 SR N5240-20007 1
A6 multiplier board
to A20 mixer brick
W4
SR N5230-20041 2
A9 fractional-N synthesizer board J106
to A8 multiplier board J100
W5
A9 fractional-N synthesizer board J101
to A8 multiplier board J101
W6 SR N5240-20008 1
A8 multiplier board
to A19 SSLAM
W21 F N5230-60030 1 A20 mixer brick (A) to A5 SPAM board J1
W22 F N5230-60029 1 A20 mixer brick (R1) to A5 SPAM board J2
W23 F N5230-60020 1 A20 mixer brick (R2) to A5 SPAM board J4
W24 F N5230-60021 1 A20 mixer brick (B) to A5 SPAM board J5
W25
F 8120-5055 2
Rear-panel 10 MHz REF. IN
to A10 frequency reference board J2
W26
A10 frequency reference board J3
to rear-panel 10 MHz REF. OUT
W27 F N5230-60024 1
A10 frequency reference board J10
to A5 SPAM board J3
W28 F N5230-60010 1
A10 frequency reference board J12
to A7 fractional-N synthesizer board J105
W29 F N5230-60011 1
A10 frequency reference board J11
to A9 fractional-N synthesizer board J105
➀
40R 8121-0116 1
A3 front panel interface board J7
to A14 system motherboard J1
➁
Refer to “Internal Hardware and Miscellaneous Parts, All Options” on page 6-26.
➂
50R 8121-0817 1
A41 hard disk drive assembly
to A15 CPU board
➃
6W N5230-60015 1
Rear panel USB hub board J3
to A14 system motherboard J20
