Agilent Technologies N5230A User Manual

6-20 Service Guide N5230-90014
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230A
Bottom Cables, Active Configuration (Option F06 and F13 Combined
with Options 014 and 1E1)
Reference
Designator
Type
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable; nR = n wires in a ribbon (flat) cable; nW = n wires in a wrapped cable
Part Number Qty Description
W3, W6 SR Refer to “Top Cables, All Options” on page 6-12.
W21-W24 F Refer to “Top Cables, All Options” on page 6-12.
W30 F N5230-60031 1 A19 SSLAM J1 to A16 test set motherboard J204
W31 F N5230-60032 1 A19 SSLAM J2 to A16 test set motherboard J205
W32 F N5230-60033 1 A19 SSLAM J3 to A16 test set motherboard J206
W40 SR N5240-20023 1 A19 SSLAM to A25 step attenuator
W41 SR N5240-20024 1 A19 SSLAM to A26 step attenuator
W42 SR N5240-20021 1 A25 step attenuator to PORT 1 SOURCE OUT
W43 SR N5240-20022 1 A26 step attenuator to PORT 2 SOURCE OUT
W44
SR N5240-20013 2
PORT 1 CPLR THRU to A21 test port 1 coupler
W45 PORT 2 CPLR THRU to A22 test port 2 coupler
W46 SR N5240-20034 1 A19 SSLAM (R1) to REFERENCE 1 SOURCE OUT
W47 SR N5240-20036 1 A19 SSLAM (R2) to REFERENCE 2 SOURCE OUT
W48 SR N5240-20011 1 A21 test port 1 coupler to PORT 1 CPLR ARM
W49 SR N5240-20012 1 A22 test port 2 coupler to PORT 2 CPLR ARM
W50 SR N5240-20009 1 PORT 1 RCVR A IN to A20 mixer brick (A)
W51 SR N5240-20017 1 REFERENCE 1 RCVR R1 IN to A20 mixer brick (R1)
W52 SR N5240-20018 1 REFERENCE 2 RCVR R2 IN to A20 mixer brick (R2)
W53 SR N5240-20010 1 PORT 2 RCVR B IN to A20 mixer brick (B)
W60 SR 08720-20098 6 Front panel jumper
➀
100R 8121-0118 1 A14 system motherboard J8 to A16 test set motherboard J1
➁
50R 8121-0817 1 A41 hard disk drive to A15 CPU board
➂
4W 8121-0802 1 Front panel LED board J1 to A16 test set motherboard J502
➃
6W N5230-60015 1 USB hub board J3 to A14 system motherboard J20
➄
26R N5230-60027 1 A19 SSLAM J4 to A16 test set motherboard J4
➅
16R N5230-60013 1 A20 mixer brick J1 to A16 test set motherboard J12
➆
10R 8121-0819 1 A25 step attenuator to A16 test set motherboard P510
➇
10R 8120-5537 1 A26 step attenuator to A16 test set motherboard P512
