6-8 Service Guide N5230-90014
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230A
Front Panel Assembly, All Options
Reference
Designator
Part Number Qty Description
A1 E8356-60001 1 Keypad assembly
A2
a
a. When ordering a replacement A2 display assembly, you must also order item
➃
.
E8356-60002 1 Display assembly
0950-3379 1
Inverter board (included in A2
b
)
b. Although included in the A2 display assembly, each of these parts is also available separately. If one of these parts should
have to be replaced, it is not necessary to replace the entire A2 display assembly. For any other parts failures within the
display, replace the entire A2 display assembly.
2090-0386 1
Display lamp for LCD (included in A2
b
)
1000-1161 1
Display glass (included in A2
b
)
A3 E8361-60061 1 Front panel interface board
RPG E8356-40006 1 Front knob
➀
5041-9183
2
Front handle side trim (for analyzers with handles)
5041-9174 Trim strip, filler (for analyzers without handles)
➁
c
c. For part numbers of complete rack mount kits and handle kits, refer to “Rack Mount Kits and Handle Kits” on page 6-35.
5063-9205 2 Front handle
➂
N5240-80001
1
Front panel overlay, passive measurement configuration
N5240-80002 Front panel overlay, active measurement configuration
➃
N5230-80011
1
Nameplate, 2-port, 300 kHz–6 GHz (Option F06)
N5240-80003
Nameplate, 2-port, 300 kHz–13.5 GHz (Option F13)
➄
d
d. When ordering a replacement front frame assembly, you must also order item
➂
.
E8364-60162 1 Front frame assembly
➅
0515-0375 4 Machine screw, M3.0 x 14 pan head
➆
0515-0372 10 Machine screw, M3.0 x 8 pan head
➇
E8364-00020 1 Display cable retaining bracket
