Agilent Technologies N5230A User Manual

6-24 Service Guide N5230-90014
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5230A
Bottom Hardware and Miscellaneous Parts, All Options
Reference
Designator
Part Number Description
➀
E8361-60059 USB hub board
➁
0515-1934
Machine screw M2.5 x 6 (USB hub board
➀
)
➂
0515-0430
Machine screw M3.0 x 6 pan head (front panel LED board
➅,
coupler
brackets
➆
, A19 SSLAM, and A20 mixer brick)
➃
0515-0374 Machine screw M3.0 x 10 pan head (A25 and A26 attenuators)
➄
0515-2012 Machine screw M3.5 x 25 pan head (A21–A22 couplers)
➅
08720-60182 Front-panel LED board
➆
N5240-00003 Coupler brackets (for mounting A21–A22 couplers)
➇
0515-0664 Machine screw M3.0 x 12 pan head (A16 test set motherboard)
➈
E8364-00007 Hard disk drive shield, stationary bracket
➉
0960-0055 Termination, male SMA short circuit
