Service Guide N5230-90014 3-3
PNA Series Microwave Network Analyzers Tests and Adjustments
N5230A Information in This Chapter
System Verification
What the system verification does.
How to perform the verification test.
How to interpret the results.
Page 3-19
Performance Tests
(Agilent N7840A
Software Package)
a
A brief summary of each performance test in the
Agilent N7840A software package:
• Source Maximum Power Output Test
• Source Power Linearity Test
• Frequency Accuracy Test
• Trace Noise Test
• Receiver Compression Test
• Noise Floor Test
• Calibration Coefficients Test
• Dynamic Accuracy Test
Page 3-28
Adjustments
Setups and procedures for adjusting your analyzer:
• 10 MHz Frequency Reference Adjustment
• LO Power Adjustment
• Source Calibration Adjustment
• Receiver Calibration Adjustment
Page 3-35
a. The Agilent N7840A software package must be purchased separately.
Section Title Summary of Content Start Page
To Next Page
