16
TriScroll 600 Dry Scroll Vacuum Pump
D R A F T 4 / 2 9 / 0 4
12. Remove and discard the six O-rings from
the three sync bearing bores in the orbiting
plate.
13. Heat the orbiting plate for a minimum of
1 hour in a 350
o
F oven.
TriScroll 600 Disassembly (continued)
WARNING This step requires the use
of heat resistant gloves. Do
not proceed without them!
