Agilent Technologies TriScroll 600 Series Major Maintenance Manual

66
TriScroll 600 Dry Scroll Vacuum Pump
D R A F T 4 / 7 / 1 1
Callout Part Number Description
Quantity
PTS06103UNIV PTS06101UNIV PTS06003UNIV PTS06001UNIV
S4744001 TriScroll Pump
Front Label
1 1 1 1
NSS* M5x22 SHCS,
Black Steel
6 6 6 6
NSS* M5x16 SHCS,
Black Steel
5 5 5 5
S4703001 VDS4 -
Outboard Cover
1 1 1 1
MK* 2-157 Viton O-ring 1 1 1 1
S4805001 VDS20 - Cowling 1 1 1 1
NSS* N5000-75
Snap Ring
3 3 3 3
MK* VDS20- Sync
Crank Assembly
3 3 3 3
NSS* M6x55 SHCS,
Black Steel
6 6 6 6
NSS* VDS20 -
Outboard Housing
1 1 1 1
MK* 2-127 Viton O-ring 1 1 1 1
S4809001 VDS20-NW40
Intake Fitting
1 1 1 1
S4824001 VDS20 -
Intake Screen
1 1 1 1
NSS* N5000-137
Snap Ring
1 1 1 1
S4808001 VDS20 -
Intake Clamp
1 1 1 1
NSS* M6x16
Steel Dowel Pin
2 2 2 2
MK = Included in major maintenance kit
TSK = Included in tip seal kit
NSS = Not sold separately
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
18
