Agilent Technologies TriScroll 600 Series Major Maintenance Manual

67
TriScroll 600 Dry Scroll Vacuum Pump
D R A F T 4 / 7 / 1 1
TSK* & MK* VDS4 - Tip Seal 1 1 1 1
NSS* N5000-225
Snap Ring
1 1 1 1
S4819001 VDS20 -
Orbiting Cup
1 1 1 1
TSK* & MK* 2-137 Viton O-ring 1 1 1 1
617919032 Spieth Locknut 1 1 1 1
NSS* VDS20 - Orbiting
Plate Assembly
1 1 1 1
TSK* & MK* 2-273 Viton O-ring 1 1 1 1
NSS* TS600
Inboard Assembly
- - 1 1
642971040 Breather Vent - - 1 1
NSS* 1/4 Brass Plug 2 2 1 1
670086120 Spider, L075 Open 1 1 1 1
622471058 Coupling,
L075 W/15 mm
Key
1 1 1 1
NSS* M8x16 SHCS 4 4 4 4
NSS* M6x16 SHCS 4 4 4 4
611810025 M8x1.25 Eye Bolt 1 1 1 1
S4841001 VDS20 - Single
Phase Motor
- 1 - 1
S4842001 VDS20-1 HP 3
Phase Motor
1 - 1 -
S4804001 VDS20 -
Transition Frame
1 1 1 1
648099055 Rubber Foot 4 4 4 4
Callout Part Number Description
Quantity
PTS06103UNIV PTS06101UNIV PTS06003UNIV PTS06001UNIV
MK = Included in major maintenance kit
TSK = Included in tip seal kit
NSS = Not sold separately
19
20
21
22
23
24
25
26
27
28
29
30
31
32
34
35
36
37
38
